Air Dryer

BLOWER HEATER NON PURGE TYPE-BHNP

- 3,500 ~ 35,000SCMH (2,060 ~ 20,600SCFM)

- Pressure due point -40ºC to -110ºC (-40 °F to -166 °F)

- ISO 8573-1 Air quality based on the grade of compressed air purity

COMPRESSED AIR HEATER NON PURGE TYPE-CHNP

- Air dryer, desiccant air dryer

- Air dryer of recycling 2-step compressed heat

- 3100 ~ 28,000 SCMH (1,824.6 ~ 16,480.2 SCFM)

- Pressure due point -40℃ ~ -100 ℃ (-40 °F ~ -148 °F)

BLOWER HEATER PURGE TYPE-BHP

- Air dryer, desiccant air dryer

- Heater fan heat recycling

- 1,000 ~ 20,000 SCMH (588.6 ~ 11,771.6 SCFM)

- Heater fan heat recycling -40 ℃ ~ -100 ℃ (-40 °F ~ -148 °F)

PRESSURE SWING HEATERLESS TYPE-PSH

- Air dryer, desiccant air dryer

- Unheated recycling

- 230 ~ 6,000 SCMH (135.4 ~ 3,531.5 SCFM)

- Pressure due point -40 ℃ ~ -100 ℃ (-40 °F ~ 148 °F)

- ISO compressed air purity grade: 0-2

COMPRESSED AIR HEATER PURGE TYPE-CHP

- 500 ~ 10,000 SCMH (294.3 ~ 5,885.8 SCFM)

- Pressure due point -40 ℃ ~ -100 ℃ (-148 °F)

- ISO compressed air purity grade: 0-2

CO2 REMOVAL DRYER
BLOWER HEATER SEMI NON PURGE TYPE - BHNP

- 500 ~ 15,000 SCMH (294 ~ 8,828SCFM)

- Pressure due point -40 ℃ to -80 ℃ (-40 ℉ to ~ 112 ℉)

- CO2 PURITY : 5PPM UNDER

- PURGE RATE : AVG. 5% ~ 7.5%

COMPRESSED HEATER PURGE TYPE - CHP

- 500 ~ 15,000 SCMH (294 ~ 8,828SCFM)

- Pressure due point -40 ℃ to -80 ℃ (-40 ℉ to ~ 112 ℉)

- CO2 PURITY : 5PPM UNDER

- PURGE RATE : 15%

Cost of initial installation
High Small
High Small

PSH

  • - Suitable for small-quality, small-size items

CHP

  • - Supply at the lowest dew point

BHP

  • - Dry air not necessary

CHNP

  • - Closed circuit configuration
  • - Very few fixed factors
  • - Coolant required

BHNP

  • - Closed circuit configuration
  • - Dry air not necessary
  • - Coolant required
Coolant required
High Small
High Small

PSH

  • - AIR LOSS 12%

CHP

  • - AIR LOSS 8%

BHP

  • - Low operation cost compared to a heater purge
  • - AIR LOSS 4%

CHNP

  • - Use of compressed air from a compressor (low heater capacity)
  • - AIR LOSS 0%

BHNP

  • - Operation cost, 90% of that of a hetaerless system
  • - AIR LOSS 0%
